Magnesia carbon brick is produced by high pressure molding process, using high purity, high density fused magnesia or large crystal magnesia and high purity graphite as raw materials.
As a kind of composite refractory material, magnesia carbon brick effectively utilizes the strong slag resistance of magnesia and the high thermal conductivity and low expansion of carbon to compensate for the poor spalling resistance of magnesia.
PRODUCT ADVANTAGES
High Strength and Good Slag Resistance
Steel ladle refractory materials are engineered with high structural strength and excellent slag resistance to ensure stable performance in demanding steelmaking environments.
Excellent thermal shock resistance
Ensures stable performance under rapid temperature changes and thermal cycling conditions, making it ideal for ladle and converter applications.
Superior chemical corrosion resistance
Maintains structural integrity even when exposed to highly corrosive slag, molten steel, and aggressive chemical environments.
Improved thermal conductivity
The presence of carbon enhances heat transfer efficiency inside high-temperature equipment, promoting faster and more uniform heat distribution.
Better temperature control and energy efficiency
Optimized heat distribution helps achieve stable operating temperatures while reducing energy consumption in steelmaking processes.
High mechanical strength
Capable of withstanding heavy loads, severe abrasion, and mechanical stress, ensuring long service life under demanding industrial conditions.
Send Your Furnace Requirements – We provide customized Magnesia carbon brick solutions for your application
TECHNICAL SPECIFICATIONS
|
Index |
MT-14A |
MT-14B |
MT-14C |
MT-14D |
|
MgO % ≥ |
77 |
76 |
74 |
72 |
|
C % ≥ |
14 |
14 |
14 |
14 |
|
Apparent porosity % ≤ |
3 |
3.5 |
4.0 |
5.0 |
|
Bulk density g/cm3 ≥ |
2.97 |
2.97 |
2.95 |
2.88 |
The slag line is one of the most severely attacked areas in a steel ladle due to direct contact with aggressive slag.
Magnesia carbon bricks provide:
MgO-C bricks are widely used in working linings where they contact molten steel and experience continuous thermal and chemical stress.
Depending on steelmaking conditions, magnesia carbon bricks can also be selected for other high-wear areas requiring high-temperature durability.
Selecting the right MgO-C brick requires consideration of actual steel plant operating conditions.
| Selection Factor | Influence on Product Selection |
|---|---|
| Steel Grade | Different steel grades create different chemical corrosion conditions |
| Slag Composition | Slag basicity and oxidation level affect corrosion resistance requirements |
| Ladle Capacity | Larger ladles may require higher mechanical strength |
| Refining Process | LF, RH, VD and other processes create different thermal conditions |
| Service Life Target | Higher campaign life requires optimized refractory grades |
| Wear Location | Slag line, bottom and sidewall require different performance characteristics |
Guoliang can recommend suitable magnesia carbon brick solutions based on customer operating conditions and refractory requirements.
Different steel plants require different refractory performance levels. Guoliang provides customized magnesia carbon brick solutions according to:
Adjustment of:
to achieve different performance requirements.
Customized sizes and shapes are available according to:
Solutions can be optimized according to:
| Comparison | Magnesia Carbon Brick | Traditional Basic Refractory Brick |
|---|---|---|
| Main Material | Magnesia + Graphite | Mainly oxide-based materials |
| Thermal Shock Resistance | Excellent | Moderate |
| Slag Resistance | High | Depends on material |
| Carbon Content | Contains graphite | Usually no graphite |
| High Temperature Performance | Excellent | Depends on grade |
| Steel Ladle Application | Widely used in high-wear areas | Used according to specific conditions |
Guoliang specializes in steel ladle refractory solutions, including magnesia carbon bricks, sliding gate plates, nozzles, plugs, castables, and other functional refractory products.
Guoliang applies strict quality control from raw materials to finished products, including chemical composition and physical performance testing.
We provide MgO-C brick solutions according to steel plant conditions, helping customers optimize refractory performance and service life.
Guoliang has experience supplying refractory products for international markets and supporting steel industry customers worldwide.
What is magnesia carbon brick used for?
Magnesia carbon bricks are mainly used in steelmaking applications such as steel ladle slag lines, working linings, converters, and electric furnaces where high slag resistance and thermal shock resistance are required.
Why are MgO-C bricks used in steel ladles?
MgO-C bricks combine the high-temperature resistance of magnesia with the thermal shock resistance and slag resistance provided by graphite, making them suitable for demanding steel ladle environments.
How to choose the right magnesia carbon brick grade?
The suitable grade depends on steel grade, slag composition, refining process, ladle capacity, wear area, and expected service life.
Can Guoliang customize magnesia carbon bricks?
Yes. Guoliang provides customized MgO-C brick solutions based on customer drawings, operating conditions, and technical requirements.
Looking for a reliable magnesia carbon brick supplier for your steel ladle refractory applications?
Guoliang provides high-performance MgO-C bricks with customized solutions for steel plants, helping improve refractory durability, reduce maintenance frequency, and optimize ladle operation.
Contact us with your ladle specifications, required brick dimensions, or current refractory challenges to receive professional recommendations and quotation.
