Guoliang company owns three wholly-owned subsidiaries and one branch. It is a high-tech enterprise specializing in the integrated solution of refractories for high-temperature industry, providing customers with general contracting services and refractory products.
Tundish Impact Pot can effectively alter the flow trajectory of molten steel in the tundish, promoting the flotation of inclusions and thereby improving steel purity. It is a crucial functional product for achieving the metallurgical functions of the tundish.
GUOLIANG provides Tundish Impact Pots in corundum, magnesia, magnesia-alumina and magnesia-siliceous material systems to meet different steelmaking and tundish operating requirements.
Share:
PRODUCT ADVANTAGES
The Tundish Impact Pot production adopts a fully automated batching system and a strict quality control system to ensure the stability of product quality.
TECHNICAL SPECIFICATIONS
|
BRAND |
Corundum |
Magnesia |
Magnesia-alumina |
Magnesia siliceous |
|
Al2O3 (%) |
≥90 |
|
≥80 |
|
|
MgO (%) |
|
≥85 |
≥52 |
|
|
Bulk density（g/cm3） |
≥3.0 |
≥2.85 |
≥2.85 |
≥2.75 |
|
Modulus of Rupture(MPa) |
≥10 |
≥8 |
≥8 |
≥5 |
|
Cold Crushing Srength（MPa) |
≥80 |
≥70 |
≥70 |
≥50 |
When molten steel enters the tundish through the ladle shroud, the incoming stream carries significant kinetic energy. Without adequate protection, repeated steel impact can accelerate erosion of the refractory lining in the impact zone.
The Impact Pot acts as both a refractory protection component and a tundish flow-management component.
Its main functions include:
Tundish dimensions, strand configurations and ladle shroud positions vary between continuous casting lines. Therefore, GUOLIANG provides custom Impact Pots based on customer drawings and operating conditions.
Customization can include:
For replacement projects, customers can provide existing impact pot drawings, dimensions or samples for evaluation.
GUOLIANG specializes in refractory materials and functional refractory components for steelmaking and continuous casting.
Our Tundish Impact Pots are manufactured using an automated batching system together with a controlled quality-management process to help maintain consistent product performance.
In addition to Impact Pots, GUOLIANG provides a range of tundish refractory products, allowing customers to source compatible refractory components for continuous casting systems.
The Impact Pot is installed in the tundish impact area, where molten steel enters the tundish from the ladle through the ladle shroud.
It helps protect the refractory lining from direct steel-stream impact while dissipating incoming flow energy and modifying molten steel flow inside the tundish.
GUOLIANG offers corundum, magnesia, magnesia-alumina and magnesia-siliceous material systems according to different operating requirements.
Yes. GUOLIANG can produce custom Tundish Impact Pots according to tundish drawings, dimensions, installation conditions and continuous casting parameters.
Selection depends on steel grade, casting temperature, slag chemistry, tundish lining system, casting sequence and expected service requirements.
Please provide the required dimensions or drawings, refractory material requirements if specified, tundish capacity, steel grade, operating conditions and required quantity.
Send us your tundish drawing, impact pot dimensions, steel grade and casting conditions. GUOLIANG can recommend a suitable refractory material and Impact Pot design for your continuous casting process.
